Active radar detector
Active radar detector
video

Active radar detector

JR1 radar is a three-coordinate radar with pulse Doppler system with azimuth machine sweep and pitch dimension scanning, which is mainly used for detection and positioning of low-altitude aircraft, ground moving vehicles and personnel. The radar can accurately detect the spatial position of the target, and can be connected to the optoelectronic system,which can be cascaded with countermeasures such as jamming, laser weapons,and navigation decoy.

Category:

Key Words:

  • Product Detail
  • parameter
  • Contents  R-02C





    Detection Distance

    Drones(RCS=0.01m2) 8km
    People(RCS=0.7m2) 16km
    Vehicle 32km
    Boat(RCS=1m2) 16km



    Detection Precision

    Distance ≤8m
    Angles ≤0.5°
    Up/Down ≤0.5°
    Coverage Directions:0°~360°Up/Down:0°~30°
    Data Rates 6s/r
    Weight ≤65kg
    Size 1030×380×700mm
    Characteristic Three coordinate radar, azimuth machine scanning + pitch phase scanning, is suitable for networking of multiple stations in the same area, and can be used for vehicle mounted erection and fixed erection.

    active radar drone detector

    With the widespread use of drones, their illegal flight poses numerous risks to public and military safety. Our active radar drone detector is a sophisticated device meticulously developed to address this issue.

    The active radar drone detector utilizes advanced active radar technology, actively emitting electromagnetic signals and receiving reflected echoes to accurately detect nearby drone activity. Its detection range is extremely wide, reaching a maximum radius of several kilometers. It effectively covers key areas such as large-scale events, military bases, and airports, providing comprehensive airspace security for these locations.

    It demonstrates exceptional detection accuracy, accurately identifying drones of varying types and sizes, from small consumer drones to large professional drones. Furthermore, it monitors detailed information such as a drone's flight path, speed, and altitude in real time. If any unusual flight behavior, such as entering a no-fly zone or circling for extended periods, is detected, the system immediately issues an alarm, notifying personnel to take appropriate action.

    The active radar drone detector is highly stable and reliable. Utilizing industrial-grade design and manufacturing processes, it can withstand a variety of complex environmental conditions, operating effectively in high and low temperatures, humid conditions, and even dusty weather. It also features anti-interference capabilities, effectively eliminating the effects of external electromagnetic interference and ensuring accurate detection results.

    Operation is simple and convenient. Equipped with an intuitive user interface and intelligent control system, it's easy to use, even for those without technical expertise. Furthermore, it supports remote monitoring and management, allowing users to view the detector's operating status and detection data anytime, anywhere via the internet.

    Our active radar drone detector is a high-performance, powerful airspace security device that can safeguard your airspace.



    • Anti interference Module

      • Elements
      • Bands

Applications

Defense and Security

Defense and Security

Protecting critical infrastructure, military installations, and public events from potential drone threats.

Aviation

Aviation

Safeguarding airports and airspace from unauthorized drone incursions that could jeopardize flight safety.

Energy

Energy

Securing power plants, oil refineries, and renewable energy facilities from espionage or sabotage by rogue drones.

Public Safety

Public Safety

Enhancing the safety of large public gatherings, such as sports events and concerts, by preventing disruptive or dangerous drone activities.

Commercial and Industrial

Commercial and Industrial

Ensuring the security of corporate campuses, industrial sites, and private properties from drone-related risks.
