0-6Ghz full bands jamming system
JJ3 is a high-power omnidirectional fixed uav countermeasures equipment, which is connected to external mains power and can realize single frequency control. The equipment adopts narrow band interference technology and radio frequency suppression technology to cut off the connection between the uav and the remote control, thus forcing the uav to return forcibly. In addition, after the UAV is controlled, it will cut off the image transmission channel, which will not transmit video, aerial photos and can not receive any instructions from the remote control on the ground, so as to achieve the protection of key areas and prevent privacy leakage.
Category:
Key Words:
Stationary detection equipment D5F
D5F
Stationary
- Product Detail
- parameter
-
Jamming frequency bands:
433MHz, 900MHz, 1.2GHz, 1.4GHz, 1.6GHz, 2.4GHz, 5.2GHz, 5.8GHz
Supporting from 30MHz to 6GHzBands supported 433MHz, 900MHz, 1.2GHz, 1.4GHz, 1.6GHz, 2.4GHz, 5.2GHz, 5.8GHz Countermeasure ability
Return, landing Countermeasure distance
3000m Counterpoint Angle
360°
Duration of flight
24 hours Power connection mode
110 /220V municipal electricity
Size Growth, height and thickness: 500 * 480 * 280mm
Weight 30 kg
Note: OEM customization: module frequency band, power, screen printing can be customized according to customer requirements
-
-
Anti interference Module
- Elements
- Bands
-
Applications
Defense and Security
Protecting critical infrastructure, military installations, and public events from potential drone threats.
Aviation
Safeguarding airports and airspace from unauthorized drone incursions that could jeopardize flight safety.
Energy
Securing power plants, oil refineries, and renewable energy facilities from espionage or sabotage by rogue drones.
Public Safety
Enhancing the safety of large public gatherings, such as sports events and concerts, by preventing disruptive or dangerous drone activities.
Commercial and Industrial
Ensuring the security of corporate campuses, industrial sites, and private properties from drone-related risks.
